Oxford Alloys Metallic Luster ER70S-2 Carbon Steel Bare Rod, 1/8 Inch dia. x 36 Inch L, (10 lb Tube) NEW SURPLUS
Detailed Description
Oxford Alloy ER70S-2 is a triple deoxidized (aluminum, titanium, zirconium) welding wire. The less fluid weld puddle of Oxford Alloy ER70S-2 makes it easier to control when used out of position. This wire is preferred for all position welding of small diameter pipe
Features
100% argon shielding gas for TIG (GTAW)
98% argon + 2% oxygen/75% argon + 25% Co2 shielding gas for MIG (GMAW) spray transfer
100% Co2/75% argon + 25% Co2 shielding gas for MIG (GMAW) short circuiting transfer
15 - 20 volt TIG (GTAW)
Oxford Alloys® 70S-21/8X36 Carbon Steel Bare Rod, Diameter: 1/8 Inch, Length: 36 Inch, Amperage: 175 - 250 amp TIG (GTAW), Package: 50 lb Box (Tube), AWS Class: AWS 5.18: ER70S-2, Metallic Luster, Tensile Strength: 79750 psi, Yield Strength: 71050 psi, Elongation in 2" (%): 29%, Welding Process: TIG (GTAW)/MIG/SAW, Weld Metal Composition: 0.07% Carbon (C), 0.90 - 1.40% Manganese (Mn), 0.40 - 0.70% Silicon (Si), 0.025% Phosphorus (P), 0.035% Sulphur (S), 0.15% Nickel (Ni), 0.15% Chromium (Cr), 0.15% Molybdenum (Mo), 0.03% Vanadium (V), 0.05 - 0.15% Aluminum (Al), 0.02 - 0.12% Zirconium (Zr), 0.05 - 0.15% Titanium (Ti), 0.50% Copper (Cu), Applicable Materials: Mild, Low Alloy Steel
Technical Details
Amperage
175 - 250 amp TIG (GTAW)
Applicable Materials
Mild, Low Alloy Steel
AWS Class
AWS 5.18: ER70S-2
Color
Metallic Luster
Diameter
1/8 Inch
Elongation in 2" (%)
29%
Length
36 Inch
Package
50 lb Box (Tube)
Tensile Strength
79750 psi
Weld Metal Composition
0.07% Carbon (C), 0.90 - 1.40% Manganese (Mn), 0.40 - 0.70% Silicon (Si), 0.025% Phosphorus (P), 0.035% Sulphur (S), 0.15% Nickel (Ni), 0.15% Chromium (Cr), 0.15% Molybdenum (Mo), 0.03% Vanadium (V), 0.05 - 0.15% Aluminum (Al), 0.02 - 0.12% Zirconium (Zr), 0.05 - 0.15% Titanium (Ti), 0.50% Copper (Cu)
Welding Process
TIG (GTAW)/MIG/SAW
Yield Strength
71050 psi
